Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
F9-15 2nd fault type / / Ɣ
F9-16 Latest fault type
acceleration
Err03: Over-current during
deceleration
Err04: Over-current at constant
speed
Err05: Over-voltage during
acceleration
Err06: Over-voltage during
deceleration
Err07: Overvoltage at constant
speed Err08: Control power fault
Err09: Under-voltage protection
Err10: AC drive overloaded
Err11: Motor overloaded
Err12: Phase loss at input side
Err13: Phase loss at output side
Err14: Module overheated
Err15: External device fault
Err16: Communication fault
Err17: Contactor fault
Err18: Current detection fault
Err19: Motor auto-tuning fault
Err20: Encoder fault
Err21: Parameter storage fault
Err23: Ground short-circuit fault
Err25: Output cable breaking
protection
Err26: Communication fault between
the control board and the main circuit
Err32: Brake feedback abnormal
Err33: Running command fault
Err35: Joystick not returned
Err37: Frequency direction abnormal
Err38: Frequency following abnormal
/ / Ɣ
F9-17 Frequency upon fault / / / Ɣ
F9-18 Current upon fault / / / Ɣ
F9-19
Bus voltage upon
fault
/ / / Ɣ
Group FA: Crane time sequence functions
FA-00
FWD startup
frequency 1
0.00–50.00 Hz
0.01 Hz 2.00 Hz ƾ
FA-01
REV startup
frequency 1
0.00–50.00 Hz
0.01 Hz 2.00 Hz ƾ
FA-02
FWD brake release
current 1
0.0%–100.0% (rated motor current)
0.1% 30.0% ƾ
FA-03
REV brake release
current 1
0.0%–100.0% (rated motor current)
0.1% 30.0% ƾ
FA-04 Brake release time 1 0.0–10.0s 0.1s 0.5s ƾ
FA-05
Brake apply
frequency 1
0.00–50.00 Hz 0.01 Hz 2.00 Hz ƾ
FA-06 Brake apply time 1 0.0–10.0s 0.1s 0.5s ƾ
FA-08 DC braking current 0%–100% 0% 0% ƾ
FA-10
DC braking output
time
0.0–10.0s 0.1s 0.0s ƾ
FA-11
DC braking waiting
time
0.0–10.0s 0.1s 0.0s ƾ
FA-12 DC braking start 0.00–20.00 Hz 0.01 Hz 0.00 Hz ƾ
