Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
command
FB-15
Frequency abnormal
detection cycle
0–5.0s 0.1s 0.5s ƾ
FB-16
Frequency tracing
deviation
0%–30% 1% 20% ƾ
Group FC: Multi-speed
FC-00 Multi-speed 0
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-01 Multi-speed 1
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-02 Multi-speed 2
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-03 Multi-speed 3
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-04 Multi-speed 4
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-05 Multi-speed 5
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-06 Multi-speed 6
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-07 Multi-speed 7
0.00 Hz to "Maximum frequency"
(F0-10)
0.01 Hz 50.00 Hz ƾ
FC-08
A
cceleration time 0 0.1–1000.0s 0.1s 3.0s ƾ
FC-09 Deceleration time 0 0.1–1000.0s 0.1s 3.0s ƾ
FC-10
A
cceleration time 1 0.1–1000.0s 0.1s 10.0s ƾ
FC-11 Deceleration time 1 0.1–1000.0s 0.1s 10.0s ƾ
Group FD: Communication parameters
FD-00 Baud rate
0: 300 bps
1: 600 bps
2: 1200 bps
3: 2400 bps
4: 4800 bps
5: 9600 bps
6: 19200 bps
7: 38400 bps
1 5 ƿ
FD-01 Data format
0: No parity check, data format: <8,
N, 2>
1: Even parity check, data format:
<8, E, 1>
2: Odd parity check, data format: <8,
O, 1>
1 0 ƿ
FD-02 Local address
1–247
0: broadcast address
1 1 ƿ
FD-03 Response delay 0–20 ms 1 2 ƿ
FD-04
Communication
timeout time
0: Invalid
0.1–60.0s
0.1s 0.0 ƿ
FD-05
Communication
protocol
0: Non-standard Modbus
1: Standard Modbus
1 0 ƿ
Group FE: Reserved
Group FF: Factory parameters
Group FP: User password
