Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
FP-00
User password 0–65535
1 0 ƿ
FP-01
Parameter
initialization
0: No operation
1: Restore factory settings except
motor parameters
2: Clear fault records
3: Check user setting
1 0 ƾ
Group FH: Motor 2 parameters
FH-00
Motor 2 type
selection
0: Common asynchronous motor
1: Variable frequency asynchronous
motor
1 0 ƾ
FH-01 Rated motor 2 power 0.4–1000.0 kW 0.1 kW
Model
dependent
ƾ
FH-02
Rated motor 2
voltage
0–800 V 1 V 38 0V ƾ
FH-03
Rated motor 2
current
0.01–655.35 A ( 55 kW)
0.1–6553.5 A (> 55 kW)
0.01A(
55 kW)
0.1A (> 55
kW)
Model
dependent
ƾ
FH-04
Rated motor 2
frequency
0.00 to maximum frequency 0.01 Hz 50.00 Hz ƾ
FH-05
Rated motor 2
rotational speed
0–30000 RPM 1 RPM 1460 RPM ƾ
FH-06
Motor 2 stator
resistance
ƿ
FH-07
Motor 2 rotor phase
resistance
0.001–65.535  ( 55 kW)
0.0001–6.5535  (> 55 k W)
0.001(
55 kW);
0.0001(
> 55 kW)
Model
dependent
ƿ
FH-08
Motor 2 Leakage
inductance
0.01–655.35 mH ( 55 kW)
0.001–65.535 mH (> 55 kW)
0.01 mH(
55 kW);
0.001 mH
(> 55 kW)
Model
dependent
ƿ
FH-09
Motor 2 mutual
inductance
0.1–6553.5 mH ( 55 kW)
0.01–655.35 mH (> 55 kW)
0.1 mH(
55 kW);
0.01 mH(>
55 kW)
Model
dependent
ƿ
FH-10
Motor 2 no-load
excitation current
0.01–650.00 A ( 55 kW)
0.1–6500.0 A (> 55 kW)
0.01 A(
55 kW);
0.1 A (>
55 kW)
Model
dependent
ƿ
FH-11
Motor 2 auto-tuning
mode
0: No auto-tuning
1: Static auto-tuning (certain motor
parameters obtained)
2: Complete auto-tuning (complete
motor parameters obtained)
3: Static auto-tuning (complete motor
parameters obtained)
1 0 ƾ
FH-12
Speed loop
proportional gain 1 o
f
motor 2
0–100 1 60 ƿ
FH-13
Speed loop integral
time 1 of motor 2
0.01–10.00s 0.01s 0.50s ƿ
FH-14
Switchover
frequency 1 of motor
2
0.00 to F2-05 0.01 Hz 5.00 Hz ƿ
FH-15
Switchover
0–100 1 20 ƿ
