Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
frequency 1 of motor
2
FH-16
Speed loop
proportional gain 2 o
f
motor 2
0.01–10.00s 0.01s 1.00s ƿ
FH-17
Speed loop integral
time 2 of motor 2
F2-02 to maximum frequency 0.01 Hz 10.00 Hz ƿ
FH-18
Vector control slip
compensation
coefficient of motor 2
50%–200% 1% 100% ƿ
FH-19
Filter time constant
of speed loop for
motor 2
0.000–0.100s 0.001s 0.000s ƿ
FH-20
Motor 2 torque
control
0: Valid
1: Invalid
1 0 ƿ
FH-21
Torque upper limit
source of motor 2
0: F2-10
1: AI1
2: AI2
3: AI3
5: Via communication
Range of analog input corresponds
to F2-10
1 0 ƿ
FH-22
Torque upper limit of
motor 2
0.0%–200.0% 0.1% 150.0% ƿ
FH-23
PPR of the encoder
for motor 2
1–65535 1 1024 ƾ
FH-24 Motor 2 control mode
0: Sensorles flux vector control
(SFVC)
1: Closed-loop vector control (CLVC)
2: Voltage/Frequency (V/F)
1 0 ƾ
FH-25
Motor 2 acceleration
time 0
0.1–1000.0s 0.1s 3.0s ƾ
FH-26
Motor 2 deceleration
time 0
0.1–1000.0s 0.1s 3.0s ƾ
FH-27
Motor 2 acceleration
time 1
0.1–1000.0s 0.1s 10.0s ƾ
FH-28
Motor 2 deceleration
time 1
0.1–1000.0s 0.1s 10.0s ƾ
FH-29 Motor 2 torque boost
0.0: Automatic torque boost
0.1%–30.0%
0.1% 1.0% ƿ
FH-30
Motor 2 oscillation
suppression gain
0–100 1
Model
dependent
ƿ
Group FL: Motor 3 parameters (defined the same as Group FH)
FL-00
Motor 3 type
selection
0: Common asynchronous motor
1: Variable frequency asynchronous
motor
1 0 ƾ
FL-01 Rated motor 3 power 0.4–1000.0 kW 0.1 kW
Model
dependent
ƾ
FL-02
Rated motor 3
voltage
0–800 V 1 V 380 V ƾ
FL-03
Rated motor 3
current
0.01–655.35 A ( 55 kW)
0.1–6553.5 A (> 55 kW)
0.01 A(
55 kW)
Model
dependent
ƾ
