Inovance CS500 User Manual

Function
Code
Parameter Name Setting Range Min. Unit Default Property
0.1 A (>
55 kW)
FL-04
Rated motor 3
frequency
0.00 to maximum frequency 0.01 Hz 50.00 Hz ƾ
FL-05
Rated motor 3
rotational speed
0–30000 RPM 1 RPM 1460 RPM ƾ
FL-06
Motor 3 stator
resistance
ƿ
FL-07
Motor 3 rotor phase
resistance
0.001–65.535  ( 55 kW)
0.0001–6.5535  (> 55 k W)
0.001(
55 kW);
0.0001(
> 55 kW)
Model
dependent
ƿ
FL-08
Motor 3 Leakage
inductance
0.01–655.35 mH ( 55 kW)
0.001–65.535 mH (> 55 kW)
0.01 mH(
55 kW);
0.001 mH
(> 55 kW)
Model
dependent
ƿ
FL-09
Motor 3 mutual
inductance
0.1–6553.5 mH ( 55 kW)
0.01–655.35 mH (> 55 kW)
0.1 mH(
55 kW);
0.01 mH(>
55 kW)
Model
dependent
ƿ
FL-10
Motor 3 no-load
excitation current
0.01–650.00 A ( 55 kW)
0.1–6500.0 A (> 55 kW)
0.01 A(
55 kW);
0.1 A (>
55 kW)
Model
dependent
ƿ
FL-11
Motor 3 auto-tuning
mode
0: No auto-tuning
1: Static auto-tuning (certain motor
parameters obtained)
2: Complete auto-tuning (complete
motor parameters obtained)
3: Static auto-tuning (complete motor
parameters obtained)
1 0 ƾ
FL-12
Speed loop
proportional gain 1 o
f
motor 3
0–100 1 60 ƿ
FL-13
Speed loop integral
time 1 of motor 3
0.01–10.00s 0.01s 0.50s ƿ
FL-14
Switchover
frequency 1 of motor
3
0.00 to F2-05 0.01 Hz 5.00 Hz ƿ
FL-15
Switchover
frequency 1 of motor
3
0–100 1 20 ƿ
FL-16
Speed loop
proportional gain 1 o
f
motor 3
0.01–10.00s 0.01s 1.00s ƿ
FL-17
Speed loop integral
time 1 of motor 3
F2-02 to maximum frequency 0.01 Hz 10.00 Hz ƿ
FL-18
Vector control slip
compensation
coefficient of motor 3
50%–200% 1% 100% ƿ
FL-19
Filter time constant
of speed loop for
motor 3
0.000–0.100s 0.001s 0.000s ƿ
FL-20
Motor 3 torque
control
0: Valid
1: Invalid
1 0 ƿ
FL-21
Torque upper limit
source of motor 3
0: F2-10
1: AI1
1 0 ƿ
efesotomas
y
on.com
