value 100% corresponds to the auxiliary frequency source range (see description of
F0-05 and F0-06). If you need to make modification on the basis of the set main
frequency, set the AI input corresponding range to -n%–+n% (F4-13 and F4-26).
z If the auxiliary frequency source is pulse setting, the principle is similar to that of
analog setting.
Main frequency source X and auxiliary frequency source Y must not use the same channel. That is,
F0-03 and F0-04 cannot be set to the same value.
Function
Code
Name Setting Range Default
F0-05
Auxiliary frequency Y selection for
X and Y superposition
0: Relative to maximum frequency
1: Relative to main frequency X
0
F0-06
Auxiliary frequency Y range for X
and Y superposition
0%–100% 0
If X and Y superposition is selected (F0-07 is set to 1 or 3), F0-05 and F0-06 are used to
set the adjustment range of the auxiliary frequency source.
F0-05 is used to set whether the auxiliary frequency is relative to maximum frequency or
main frequency X. If relative to main frequency X, the setting range of the auxiliary
frequency Y varies with the main frequency X.
Function
Code
Name Setting Range Default
0 Main frequency source X
1 X and Y superposition
2 Switchover between X and Y
3 Switchover between X and "X and Y
superposition"
F0-07
Frequency
source
selection
4 Switchover between Y and "X and Y
superposition"
0
You can select the frequency setting channel by setting this parameter. The frequency can
be set through X and Y superposition.
z If F0-07 is set to 1, the frequency source is X and Y superposition.
z If F0-07 is set to 2, the frequency source is switchover between X and Y, which is
implemented by a multifunctional DI terminal with the frequency source switchover
function.
z If F0-07 is set to 3, the frequency source is switchover between X and "X and Y
superposition", which is implemented by a multifunctional DI terminal with the
frequency source switchover function.
z If F0-07 is set to 4, the frequency source is switchover between Y and "X and Y
superposition", which is implemented by a multifunctional DI terminal with the
frequency source switchover function.
In this way, switchover between the frequency setting channels is implemented.
Function Code Name Setting Range Default
F0-08
Preset frequency 0.00 Hz to maximum frequency (valid when
frequency source is digital setting)
50.00 Hz
If the main frequency source X is terminal UP/DOWN, it is used to set the initial value of
AC drive acceleration or deceleration.
Function Code Name Setting Range Default
