ASSIST PLUS – Operating instructions V02 Programming
www.integra-biosciences.com 33
Press to save your settings. This will return you to the list of Multi aspirate programs.
Target Type Sets the target container where the sample is dispensed
(Reservoir or Plate).
Plate If plate, set the destination plate position (B or C).
Column/Row Select the column/row of the plate where the sample is
dispensed. Note: the column/row number depends on plate
orientation.
Disp. Speed Sets speed of all dispensing steps (1 = low, 10 = fast).
Height Sets the height for the dispensing steps.
Advan-
ced
Tip Travel Defines the distance which the tips move during an aspira-
tion, dispense and mix step to artificially track the liquid level,
see “7.8
Tip travel distances” on page 47.
• Source Asp: moves the set distance down during aspira-
tion in the source location.
• Source Mix: moves the set distance down and up during
mixing in the source location.
Options Steps Description of Multi aspirate
