ASSIST PLUS – Operating instructions V02 Programming
www.integra-biosciences.com 35
Press to save your settings. This will return you to the list of Plate copy programs.
5.7.5 Reformat program
Application: This program samples between plates of different well number (12, 48, 96
and 384) can be transferred to merge several plates in one plate or to split one plate in
several plates.
Advan-
ced
Tracking Chooses if the pipette automatically follows the liquid level,
see “7.8 Tip travel distances” on page 47.
• Source Asp: moves the set distance down during aspira-
tion from the source location.
• Source Mix: moves the set distance down and up during
mixing in the source location.
• Target Disp: moves the set distance up during dispensing
in the target location. The same distance is used to move
down during aspiration in the target location.
• Target Mix: moves the set distance down and up during
mixing in the target location.
Options Steps Description of Reformat
Source Plate Sets the deck position (B or C) as location for the source
plate.
Wells Sets the well plate type (12, 24, 48, 96 or 384) to be used as
source. On VOYAGER pipettes this automatically defines
the tip spacing. Note: only pipette compatible plates can be
selected, see “7.6
Plate compatibility” on page 45.
Orientation Sets the orientation of the source plate (landscape, portrait).
Note: orientation can only be changed if it is compatible with
the pipette.
Clear Height Sets the travel height at which the GripTips move above the
plates.
Tip Change If activated, tips are changed before each new aspiration.
Target Wells Sets the well plate type (12, 24, 48, 96 or 384) to be used as
target.
Orientation Sets the orientation of the target plate (landscape, portrait).
Transfer
pattern
Defines whether to complete columns (N) or rows first (Z),
see “7.7
Plate access pattern” on page 46.
Options Steps Description of Plate Copy
