7.6 Plate compatibility
The tables below provide an overview outlining the compatibilities of pipettes with different
well plates and plate orientations.
VIAFLO pipettes 96 well plate (8 x 12) 384 well plate (16 x 24)
Channels Volume
[μl]
Tip dist.
[mm]
Landscape
(8 wells)
Portrait
(12 wells)
Landscape
(16 wells)
Portrait
(24 wells)
8
12.5 9 x x
50 9 x x
125 9 x x
300 9 x x
1250 9 x
12
12.5 9 x x
50 9 x x
125 9 x x
300 9 x x
1250 9 x
16
12.5 4.5 x
50 4.5 x
125 4.5 x
VOYAGER pipettes 12 well 24 well 48 well 96 well 384 well
Channels Volume
[μl]
Spacing
[mm]
L
(3)
P
(4)
L
(4)
P
(6)
L
(6)
P
(8)
L
(8)
P
(12)
L
(16)
P
(24)
4
300 9–32.5 xx xx xx
1250 9–32.5 x x x x
6
300 9–19.5 x x x x
1250 9–19.5 x x x
8
12.5 4.5–14 x x x x
50 4.5–14 x x x x
125 4.5–14 x x x x
300 9–14 x x x x
1250 9–14 x x
12
12.5 4.5–9 x x
50 4.5–9 x x
125 4.5–9 x x
