ASSIST PLUS – Operating instructions V02 Technical Data
44 INTEGRA Biosciences AG
7.4 Compatible pipettes
The following INTEGRA pipettes are compatible with ASSIST PLUS:
7.5 Maximum labware height on deck
The maximum labware height defines the distance between pipette tip end and deck (in
mm) and depends on the pipette model and tip type:
Pipette Firmware Serial No.
VIAFLO 4.xx 7xxxxxx
VOYAGER 4.xx 7xxxxxx
Pipette Model SHORT tips Standard tips LONG tips
12.5 µl VIAFLO 213.7 205.1 196.2
12.5 µl VOYAGER 205.1 196.4 187.5
50/125 µl VIAFLO - 185.1 -
50/125 µl VOYAGER - 176.4 -
300 µl VIAFLO - 179.2 138.0
300 µl VOYAGER - 171.3 130.1
1250 µl VIAFLO 155.4 137.9 -
1250 µl VOYAGER 147.1 129.6 -
