Datasheet, Volume 1 63
Signal Description
6.2 Memory Reference and Compensation Signals
Table 6-3. Memory Channel B Signals
Signal Name Description
Direction/
Buffer Type
SB_BS[2:0]
Bank Select: These signals define which banks are selected within
each SDRAM rank.
O
DDR3
SB_WE#
Write Enable Control Signal: This signal is used with SB_RAS# and
SB_CAS# (along with SB_CS#) to define the SDRAM Commands.
O
DDR3
SB_RAS#
RAS Control Signal: This signal is used with SB_CAS# and SB_WE#
(along with SB_CS#) to define the SRAM Commands.
O
DDR3
SB_CAS#
CAS Control Signal: This signal is used with SB_RAS# and SB_WE#
(along with SB_CS#) to define the SRAM Commands.
O
DDR3
SB_DQS[8:0]
SB_DQS#[8:0]
Data Strobes: SB_DQS[8:0] and its complement signal group make
up a differential strobe pair. The data is captured at the crossing point
of SB_DQS[8:0] and its SB_DQS#[8:0] during read and write
transactions.
I/O
DDR3
SB_DQ[63:0]
Data Bus: Channel B data signal interface to the SDRAM data bus. I/O
DDR3
SB_MA[15:0]
Memory Address: These signals are used to provide the multiplexed
row and column address to the SDRAM.
O
DDR3
SB_CK[3:0]
SDRAM Differential Clock: Channel B SDRAM Differential clock signal
pair. The crossing of the positive edge of SB_CK and the negative edge
of its complement SB_CK# are used to sample the command and
control signals on the SDRAM.
O
DDR3
SB_CK#[3:0]
SDRAM Inverted Differential Clock: Channel B SDRAM Differential
clock signal-pair complement.
O
DDR3
SB_CKE[3:0]
Clock Enable: (1 per rank). Used to:
Initialize the SDRAMs during power-up.
Power-down SDRAM ranks.
Place all SDRAM ranks into and out of self-refresh during STR.
O
DDR3
SB_CS#[3:0]
Chip Select: (1 per rank). Used to select particular SDRAM
components during the active state. There is one Chip Select for each
SDRAM rank.
O
DDR3
SB_ODT[3:0]
On Die Termination: Active Termination Control. O
DDR3
Table 6-4. Memory Reference and Compensation
Signal Name Description
Direction/
Buffer Type
SM_VREF
DDR3 Reference Voltage: This provides reference voltage to the
DDR3 interface and is defined as V
DDQ
/2.
I
A
