Page #65 background imageLoading...
Page #65 background image
Datasheet, Volume 1 65
Signal Description
6.4 PCI Express*-Based Interface Signals
Notes:
1. PE_TX[3:0] and PE_RX[3:0] are only used for platforms that support 20 PCIe lanes.
6.5 Intel
®
Flexible Display Interface (Intel
®
FDI)
Signals
Table 6-6. PCI Express* Graphics Interface Signals
Signal Name Description
Direction/
Buffer Type
PEG_ICOMPI
PCI Express Input Current Compensation I
A
PEG_ICOMPO
PCI Express Current Compensation I
A
PEG_RCOMPO
PCI Express Resistance Compensation I
A
PEG_RX[15:0]
PEG_RX#[15:0]
PE_RX[3:0]
1
PE_RX#[3:0]
1
PCI Express Receive Differential Pair
I
PCI Express
PEG_TX[15:0]
PEG_TX#[15:0]
PE_TX[3:0]
1
PE_TX#[3:0]
1
PCI Express Transmit Differential Pair
O
PCI Express
Table 6-7. Intel
®
Flexible Display Interface (Intel
®
FDI)
Signal Name Description
Direction/
Buffer Type
FDI0_FSYNC[0]
Intel
®
Flexible Display Interface Frame Sync – Pipe A I
CMOS
FDI0_LSYNC[0]
Intel
®
Flexible Display Interface Line Sync – Pipe A I
CMOS
FDI_TX[7:0]
FDI_TX#[7:0]
Intel
®
Flexible Display Interface Transmit Differential Pairs O
FDI
FDI1_FSYNC[1]
Intel
®
Flexible Display Interface Frame Sync – Pipe B I
CMOS
FDI1_LSYNC[1]
Intel
®
Flexible Display Interface Line Sync – Pipe B I
CMOS
FDI_INT
Intel
®
Flexible Display Interface Hot Plug Interrupt I
Asynchronous
CMOS
