DDR Data Swizzling
Datasheet, Volume 1 111
§ §
Table 9-2. DDR Data Swizzling
Table – Channel B
Pin Name Pin # MC Pin Name
SB_DQ[0] AG7 DQ03
SB_DQ[1] AG8 DQ02
SB_DQ[2] AJ9 DQ05
SB_DQ[3] AJ8 DQ04
SB_DQ[4] AG5 DQ00
SB_DQ[5] AG6 DQ01
SB_DQ[6] AJ6 DQ06
SB_DQ[7] AJ7 DQ07
SB_DQ[8] AL7 DQ11
SB_DQ[9] AM7 DQ10
SB_DQ[10] AM10 DQ14
SB_DQ[11] AL10 DQ13
SB_DQ[12] AL6 DQ08
SB_DQ[13] AM6 DQ09
SB_DQ[14] AL9 DQ12
SB_DQ[15] AM9 DQ15
SB_DQ[16] AP7 DQ19
SB_DQ[17] AR7 DQ18
SB_DQ[18] AP10 DQ21
SB_DQ[19] AR10 DQ22
SB_DQ[20] AP6 DQ17
SB_DQ[21] AR6 DQ16
SB_DQ[22] AP9 DQ20
SB_DQ[23] AR9 DQ23
SB_DQ[24] AM12 DQ25
SB_DQ[25] AM13 DQ30
SB_DQ[26] AR13 DQ29
SB_DQ[27] AP13 DQ28
SB_DQ[28] AL12 DQ24
SB_DQ[29] AL13 DQ31
SB_DQ[30] AR12 DQ27
SB_DQ[31] AP12 DQ26
SB_DQ[32] AR28 DQ32
SB_DQ[33] AR29 DQ34
SB_DQ[34] AL28 DQ39
SB_DQ[35] AL29 DQ37
SB_DQ[36] AP28 DQ33
SB_DQ[37] AP29 DQ35
SB_DQ[38] AM28 DQ36
SB_DQ[39] AM29 DQ38
SB_DQ[40] AP32 DQ44
SB_DQ[41] AP31 DQ43
SB_DQ[42] AP35 DQ45
SB_DQ[43] AP34 DQ46
SB_DQ[44] AR32 DQ40
SB_DQ[45] AR31 DQ42
SB_DQ[46] AR35 DQ47
SB_DQ[47] AR34 DQ41
SB_DQ[48] AM32 DQ51
SB_DQ[49] AM31 DQ48
SB_DQ[50] AL35 DQ53
SB_DQ[51] AL32 DQ50
SB_DQ[52] AM34 DQ52
SB_DQ[53] AL31 DQ49
SB_DQ[54] AM35 DQ54
SB_DQ[55] AL34 DQ55
SB_DQ[56] AH35 DQ59
SB_DQ[57] AH34 DQ58
SB_DQ[58] AE34 DQ61
SB_DQ[59] AE35 DQ62
SB_DQ[60] AJ35 DQ57
SB_DQ[61] AJ34 DQ56
SB_DQ[62] AF33 DQ63
SB_DQ[63] AF35 DQ60
Table 9-2. DDR Data Swizzling
Table – Channel B
Pin Name Pin # MC Pin Name
