Electrical Specifications
80 Datasheet, Volume 1
7.10 DC Specifications
The processor DC specifications in this section are defined at the processor
pads, unless noted otherwise. See Chapter 8 for the processor land listings and
Chapter 6 for signal definitions. Voltage and current specifications are detailed in
Tab l e 7 -5, Tabl e 7 -6, and Tabl e 7 - 7 .
The DC specifications for the DDR3 signals are listed in Table 7-8 Control Sideband and
Test Access Port (TAP) are listed in Ta b le 7 - 9.
Tab l e 7 -5 through Table 7- 7 list the DC specifications for the processor and are valid
only while meeting the thermal specifications (as specified in the Thermal / Mechanical
Specifications and Guidelines), clock frequency, and input voltages. Care should be
taken to read all notes associated with each parameter.
7.10.1 Voltage and Current Specifications
Table 7-5. Processor Core Active and Idle Mode DC Voltage and Current Specifications
(Sheet 1 of 2)
Symbol Parameter Min Typ Max Unit Note
1
VID VID Range 0.2500 — 1.5200 V 2
LL
VCC
V
CC
Loadline Slope
2011D, 2011C, 2011B (processors
with 95 W, 65 W, and 45 W TDPs)
1.7 mΩ 3, 5, 6
V
CC
TOB
V
CC
Tolerance Band
2011D, 2011C, 2011B (processors
with 95 W, 65 W, and 45 W TDPs)
PS0
PS1
PS2
±16
±13
±11.5
mV
3, 5, 6,
7
V
CC
Ripple
Ripple:
2011D, 2011C, 2011B (processors
with 95 W, 65 W, and 45 W TDPs)
PS0
PS1
PS2
±7
±10
-10/+25
mV
3, 5, 6,
7
LL
VCC
V
CC
Loadline Slope
2011A (processors with 35 W TDP)
2.9 mΩ
3, 5, 6,
8
V
CC
TOB
V
CC
Tolerance Band
2011A (processors with 35 W TDP)
PS0
PS1
PS2
19
19
11.5
mV
3, 5, 6,
7, 8
V
CC
Ripple
Ripple:
2011A (processors with 35 W TDP)
PS0
PS1
PS2
±10
±10
-10/+25
mV
3, 5, 6,
7, 8
V
CC,BOOT
Default V
CC
voltage for initial
power up
—0 —V
I
CC
2011D (processors with 95 W
TDPs) I
CC
— — 112 A 4
I
CC
2011C (processors with 65 W TDP)
I
CC
——75A4
