Page #69 background imageLoading...
Page #69 background image
Datasheet, Volume 1 69
Signal Description
6.14 Processor Internal Pull-Up / Pull-Down Resistors
§ §
Table 6-16. Processor Internal Pull-Up / Pull-Down Resistors
Signal Name Pull-Up / Pull-Down Rail Value
BPM[7:0] Pull Up VCCIO 65–165 Ω
PRDY# Pull Up VCCIO 65–165 Ω
PREQ# Pull Up VCCIO 65–165 Ω
TCK Pull Down VSS 5–15 kΩ
TDI Pull Up VCCIO 5–15 kΩ
TMS Pull Up VCCIO 5–15 kΩ
TRST# Pull Up VCCIO 5–15 kΩ
CFG[17:0] Pull Up VCCIO 5–15 kΩ
