Intel BX80623I32100 User Manual

Datasheet, Volume 1 73
Electrical Specifications
Table 7-1. VR 12.0 Voltage Identification Definition (Sheet 1 of 3)
VID
7
VID
6
VID
5
VID
4
VID
3
VID
2
VID
1
VID
0
HEX V
CC_MAX
VID
7
VID
6
VID
5
VID
4
VID
3
VID
2
VID
1
VID
0
HEX V
CC_MAX
0 0 0 0 0 0 0 0 0 0 0.00000 1 0 0 0 0 0 0 0 8 0 0.88500
0 0 0 0 0 0 0 1 0 1 0.25000 1 0 0 0 0 0 0 1 8 1 0.89000
0 0 0 0 0 0 1 0 0 2 0.25500 1 0 0 0 0 0 1 0 8 2 0.89500
0 0 0 0 0 0 1 1 0 3 0.26000 1 0 0 0 0 0 1 1 8 3 0.90000
0 0 0 0 0 1 0 0 0 4 0.26500 1 0 0 0 0 1 0 0 8 4 0.90500
0 0 0 0 0 1 0 1 0 5 0.27000 1 0 0 0 0 1 0 1 8 5 0.91000
0 0 0 0 0 1 1 0 0 6 0.27500 1 0 0 0 0 1 1 0 8 6 0.91500
0 0 0 0 0 1 1 1 0 7 0.28000 1 0 0 0 0 1 1 1 8 7 0.92000
0 0 0 0 1 0 0 0 0 8 0.28500 1 0 0 0 1 0 0 0 8 8 0.92500
0 0 0 0 1 0 0 1 0 9 0.29000 1 0 0 0 1 0 0 1 8 9 0.93000
0 0 0 0 1 0 1 0 0 A 0.29500 1 0 0 0 1 0 1 0 8 A 0.93500
0 0 0 0 1 0 1 1 0 B 0.30000 1 0 0 0 1 0 1 1 8 B 0.94000
0 0 0 0 1 1 0 0 0 C 0.30500 1 0 0 0 1 1 0 0 8 C 0.94500
0 0 0 0 1 1 0 1 0 D 0.31000 1 0 0 0 1 1 0 1 8 D 0.95000
0 0 0 0 1 1 1 0 0 E 0.31500 1 0 0 0 1 1 1 0 8 E 0.95500
0 0 0 0 1 1 1 1 0 F 0.32000 1 0 0 0 1 1 1 1 8 F 0.96000
0 0 0 1 0 0 0 0 1 0 0.32500 1 0 0 1 0 0 0 0 9 0 0.96500
0 0 0 1 0 0 0 1 1 1 0.33000 1 0 0 1 0 0 0 1 9 1 0.97000
0 0 0 1 0 0 1 0 1 2 0.33500 1 0 0 1 0 0 1 0 9 2 0.97500
0 0 0 1 0 0 1 1 1 3 0.34000 1 0 0 1 0 0 1 1 9 3 0.98000
0 0 0 1 0 1 0 0 1 4 0.34500 1 0 0 1 0 1 0 0 9 4 0.98500
0 0 0 1 0 1 0 1 1 5 0.35000 1 0 0 1 0 1 0 1 9 5 0.99000
0 0 0 1 0 1 1 0 1 6 0.35500 1 0 0 1 0 1 1 0 9 6 0.99500
0 0 0 1 0 1 1 1 1 7 0.36000 1 0 0 1 0 1 1 1 9 7 1.00000
0 0 0 1 1 0 0 0 1 8 0.36500 1 0 0 1 1 0 0 0 9 8 1.00500
0 0 0 1 1 0 0 1 1 9 0.37000 1 0 0 1 1 0 0 1 9 9 1.01000
0 0 0 1 1 0 1 0 1 A 0.37500 1 0 0 1 1 0 1 0 9 A 1.01500
0 0 0 1 1 0 1 1 1 B 0.38000 1 0 0 1 1 0 1 1 9 B 1.02000
0 0 0 1 1 1 0 0 1 C 0.38500 1 0 0 1 1 1 0 0 9 C 1.02500
0 0 0 1 1 1 0 1 1 D 0.39000 1 0 0 1 1 1 0 1 9 D 1.03000
0 0 0 1 1 1 1 0 1 E 0.39500 1 0 0 1 1 1 1 0 9 E 1.03500
0 0 0 1 1 1 1 1 1 F 0.40000 1 0 0 1 1 1 1 1 9 F 1.04000
0 0 1 0 0 0 0 0 2 0 0.40500 1 0 1 0 0 0 0 0 A 0 1.04500
0 0 1 0 0 0 0 1 2 1 0.41000 1 0 1 0 0 0 0 1 A 1 1.05000
0 0 1 0 0 0 1 0 2 2 0.41500 1 0 1 0 0 0 1 0 A 2 1.05500
0 0 1 0 0 0 1 1 2 3 0.42000 1 0 1 0 0 0 1 1 A 3 1.06000
0 0 1 0 0 1 0 0 2 4 0.42500 1 0 1 0 0 1 0 0 A 4 1.06500
0 0 1 0 0 1 0 1 2 5 0.43000 1 0 1 0 0 1 0 1 A 5 1.07000
0 0 1 0 0 1 1 0 2 6 0.43500 1 0 1 0 0 1 1 0 A 6 1.07500
0 0 1 0 0 1 1 1 2 7 0.44000 1 0 1 0 0 1 1 1 A 7 1.08000
0 0 1 0 1 0 0 0 2 8 0.44500 1 0 1 0 1 0 0 0 A 8 1.08500
0 0 1 0 1 0 0 1 2 9 0.45000 1 0 1 0 1 0 0 1 A 9 1.09000
0 0 1 0 1 0 1 0 2 A 0.45500 1 0 1 0 1 0 1 0 A A 1.09500
