Intel Core i7-800 - Socket; Heatsink; ILM Keepout Zone Secondary Side (Bottom)

Thermal/Mechanical Specifications and Design Guidelines 77
Mechanical Drawings
Figure B-2. Socket / Heatsink / ILM Keepout Zone Secondary Side (Bottom)
(78.25 )
(36.00 )
(18.72 )
37.54
0.00
25.81
13.67
35.21
35.21
40.71
13.67
4X 6.00
4X 10.00
(61.02 )
4X R1.8
(52.00 )
26.00
0.00
10.80
7.05
26.00
18.00
18.00
9.36 9.36
(27.33 )
DEPARTMENT
R
2200 MISSION COLLEGE BLVD. P.O. BOX 58119 SANTA CLARA, CA 95052-8119
SIZE DRAWING NUMBER REV
A1
E21319_REV_L_PAE
L
SCALE:
1.000
DO NOT SCALE DRAWING
SHEET
2
OF
2
BOARD SECONDARY SIDE
2
2
WEST
EAST
SOUTH
NORTH
SOCKET& PROCESSOR
VOLUMETRIC KEEP-IN
INTEL PN E21320
COMPONENT VOLUMETRIC
KEEPINS
SOCKET& PROCESSOR
VOLUMETRIC KEEP-IN OUTLINE
ROUTING KEEPOUTS
LEGEND
COMPONENT KEEP-OUT ROUTING AND COMPONENT KEEP-OUT MAX COMPONENT HEIGHT 2.54MM
