Mechanical Drawings
Figure B-10. Reference Clip (Sheet 1 of 2)
13
4
5678
B
C
D
A
123
4
5678
B
C
D
A
A
A
SHEET 1 OF 2DO NOT SCALE DRAWINGSCALE: 3:1
01E36830D
REVDRAWING NUMBERCAGE CODESIZE
HAVENDALE POWER ON SAMPLE
HEAT SINK CLIP
TITLE
2200 MISSION COLLEGE BLVD.
P.O. BOX 58119
SANTA CLARA, CA 95052-8119CORP.
R
PST
DEPARTMENT
SEE NOTES
FINISH:
SEE NOTES
MATERIAL:
--
DATEAPPROVED BY
--
DATECHECKED BY
02/04/08KG TAN
DATEDRAWN BY
04/02/03R. AOKI
DATEDESIGNED BY
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN MILLIMETERS.
TOLERANCES: LINEAR .15
ANGLES: 1
INTERPRET DIMENSIONS AND TOLERANCES
PER ANSI Y14.5M-1994
THIRD ANGLE PROJECTION
REVISION HISTORY
ZONE REV DESCRIPTION DATE APPROVED
A RELEASE FOR PROTOTYPING 02/04/08 NA
E36830 1 A
DWG. NO SHT. REV
PARTS LIST
DESCRIPTIONPART NUMBERITEM NO
QTY PER ASSY
-001-002-003
CLIP, STEEL, STAMPEDE36830-001TOP
74.22 0.2
.166
.007[]
98.8
3.890[]
98.8
3.890[]
2 0.2
.079
.007[]
SQ 53.5 0.2
2.106
.007[]
4X 10 0.2
.394
.007[]
41.73
1.643[]
B
733.86 0.2
1.333
.007[]
A
()1.60
.063[]
NOTES:
1. THIS DRAWING TO BE USED IN CONJUNTION WITH SUPPLIED 3D
DATABASE FILE. ALL DIMENSIONS AND TOLERANCES ON THIS
DRAWING TAKE PRECEDENCE OVER SUPPLIED FILE AND ARE
APPLICABLE AT PART FREE, UNCONSTRAINED STATE UNLESS
INDICATED OTHERWISE.
2. MATERIAL:
A) TYPE: AISI 1065 COLD DRAWN STEEL OR EQUIVALENT
1.6MM THICKNESS .02 [.063"]
B) CRITICAL MECHANICAL MATERIAL PROPERTIES
FOR EQUIVALENT MATERIAL SELECTION:
ELASTIC MODULUS > 206.8 GPA [29,900 KSI]
MIN TENSILE YIELD STRENGTH (ASTM D638) > 380 MPa [55KSI]
C) MASS - 37.7 GRAMS (REF)
3. SECONDARY OPERATIONS:
A) FINISH: NICKEL PLATE REQUIRED AFTER FORMING
4. ALL DIMENSIONS AND TOLERANCES ARE SHOWN AFTER PLATING
5 PUNCH DIRECTION
6. BREAK ALL SHARP CORNERS AND BURRS
7 CRITICAL TO FUNCTION DIMENSION
8 COINING REQUIRED AS SPECIFIED
9. SECONDARY UNIT TOLERANCES SHOULD BE CALCULATED FROM PRIMARY
UNITS TO AVOID ROUND OFF ERROR.
7
0.5 [.01] A B
7
0.5 [.01] A B
SEE DETAIL A
REMOVE ALL BURRS OR SHARP EDGES AROUND PERIMETER OF PART.
SHARPNESS OF EDGES SUBJECT TO HANDLING ARE REQUIRED TO
MEET THE UL1439 TEST.
PERMANENTLY MARK PART
NUMBER AND REVISION LEVEL
APPROXIMATELY WHERE SHOWN
XXXXXX-XXX REV XX
SECTION A-A
SEE DETAIL B
SEE DETAIL C
SEE DETAIL D
SEE DETAIL A
SEE DETAIL B
SEE DETAIL C
SEE DETAIL D
To Next Page
