Intel Core i7-800 - D Package Mechanical Drawings; Mechanical Drawing List

Thermal/Mechanical Specifications and Design Guidelines 95
Package Mechanical Drawings
D Package Mechanical
Drawings
Ta b l e D-1 lists the mechanical drawings included in this appendix.
Table D-1. Mechanical Drawing List
Drawing Description Figure Number
“Processor Package Drawing (Sheet 1 of 2)” Figure D-1
“Processor Package Drawing (Sheet 2 of 2)” Figure D-2
