Intel Core i7-800 - C Socket Mechanical Drawings; Mechanical Drawing List

Thermal/Mechanical Specifications and Design Guidelines 89
Socket Mechanical Drawings
C Socket Mechanical Drawings
Ta b l e C-1 lists the mechanical drawings included in this appendix.
Table C-1. Mechanical Drawing List
Drawing Description Figure Number
“Socket Mechanical Drawing (Sheet 1 of 4)” Figure C-1
“Socket Mechanical Drawing (Sheet 2 of 4)” Figure C-2
“Socket Mechanical Drawing (Sheet 3 of 4)” Figure C-3
“Socket Mechanical Drawing (Sheet 4 of 4)” Figure C-4
