Desktop Board D815EEA Technical Product Specification
12
1.1 Overview
1.1.1 Feature Summary
Table 1 summarizes the D815EEA board’s major features.
Table 1. Feature Summary
Form Factor
ATX (12.0 inches by 8.2 inches)
Processor
Support for either an Intel
®
Pentium
®
III processor in a Flip Chip Pin Grid Array
(FC-PGA) package or an Intel
®
Celeron
™
processor in an FCPGA package or a
PPGA package
Memory
• Three 168-pin SDRAM Dual Inline Memory Module (DIMM) sockets
• Support for up to 512 MB system memory
• Single- or double-sided DIMMs supported
Chipset
Intel
®
815E Chipset, consisting of:
• Intel
®
82815E Graphics and Memory Controller Hub (GMCH)
• Intel
®
82801BA I/O Controller Hub (ICH2)
• Intel
®
82802AB 4 Mbit Firmware Hub (FWH)
I/O Control
SMSC LPC47M102 LPC bus I/O controller
Video
• Intel
®
82815E integrated graphics support
• AGP universal connector supporting 1X, 2X, and 4X AGP cards or a Graphics
Performance Accelerator (GPA)
• Digital video output (DVO) connector
Peripheral
Interfaces
• Four Universal Serial Bus (USB) ports
• Two serial ports
• One parallel port
• Two IDE interfaces with Ultra DMA, ATA-66/100 support
• One diskette drive interface
• MIDI/game port
• PS/2
†
keyboard and mouse ports
Expansion
Capabilities
• Five PCI bus add-in card connectors (SMBus routed to PCI bus connector 2)
• One AGP universal connector
BIOS
• Intel/AMI BIOS (resident in the Intel 82802AB 4 Mbit FWH)
• Support for Advanced Power Management (APM), Advanced Configuration and
Power Interface (ACPI), Plug and Play, and SMBIOS
Diagnostic LEDs
Four dual-color LEDs on back panel
Instantly Available
PC
• Support for
PCI Local Bus Specification Revision 2.2
• Suspend to RAM support
• Wake on PS/2 keyboard and USB ports
Wake on LAN
†
Technology
Connector
Support for system wake up using an add-in network interface card with remote
wake up capability
For information about Refer to
The board’s compliance level with APM, ACPI, Plug and Play, and SMBIOS. Section 1.3, page 16
