Intel D815EEA User Manual

Technical Reference
57
Table 24. MIDI/Game Port Connector
Pin Signal Name Pin Signal Name
1 +5 V (fused) 9 +5 V (fused)
2 JOY4 10 JOY6
3 JOYTIME0 11 JOYTIME2
4 Ground 12 MIDI-OUT
5 Ground 13 JOYTIME3
6 JOYTIME1 14 JOY7
7 JOY5 15 MIDI-IN
8 +5 V (fused)
Table 25. Audio Line Out Connector
Pin Signal Name
Tip Audio left out
Ring Audio right out
Sleeve Ground
Table 26. Audio Line In Connector
Pin Signal Name
Tip Audio left in
Ring Audio right in
Sleeve Ground
Table 27. Mic In Connector
Pin Signal Name
Tip Mono in
Ring Mic bias voltage
Sleeve Ground
