Intel
®
Desktop Board D815EEA Technical Product Specification
74
Table 51. BIOS Setup Configuration Jumper Settings (J7B1)
Function/Mode Jumper Setting Configuration
Normal
1-2
1
3
The BIOS uses current configuration information and
passwords for booting.
Configure
2-3
1
3
After the POST runs, Setup runs automatically. The
maintenance menu is displayed.
Recovery
None
1
3
The BIOS attempts to recover the BIOS configuration. A
recovery diskette is required.
For information about Refer to
How to access the BIOS Setup program Section 4.1, page 97
The maintenance menu of the BIOS Setup program Section 4.2, page 98
BIOS recovery Section 3.7, page 91
