Intel
®
Desktop Board D815EEA Technical Product Specification
34
• Crystal Semiconductor CS4297 (A) Stereo Audio Codec:
20-bit stereo digital-to-analog and 18-bit stereo analog-to-digital converters
High performance 18-bit stereo full-duplex audio codec with up to 48 kHz sampling rate
Connects to the ES1373 digital controller using a five-wire digital interface
For information about Refer to
Obtaining audio software and utilities Section 1.2, page 16
1.9.3 Audio Connectors
The audio connectors include the following:
• CD-ROM (legacy-style 2-mm connector)
• ATAPI-style connectors:
CD-ROM
Telephony
Auxiliary line in
• Back panel audio connectors:
MIDI/Game Port
Line out
Line in
Mic in
For information about Refer to
The back panel audio connectors Section 2.8.1, page 54
CAUTION
The pins on both the legacy-style 2-mm and the ATAPI CD-ROM connectors are wired to the same
inputs on the audio mixer. Do not attach CD-ROM drives to both connectors. Otherwise, the
board could be damaged.
1.9.3.1 CD-ROM (Legacy-style 2-mm) Audio Connector
A 1 x 4-pin legacy-style 2-mm connector connects an internal CD-ROM drive to the audio mixer.
For information about Refer to
The location of the legacy-style 2-mm connector Figure 10, page 59
The signal names of the legacy-style 2-mm connector Table 39, page 60
