Technical Reference
79
Table 54. Standby Current Requirements
Instantly Available
Current Support
Requirements Description
Standby Current
Requirements (mA)
Minimum
Total for the board 767
Onboard LAN (optional) 95
WOL header connected to wake enabled PCI LAN card 525
PS/2 ports (Note) 345
AGP and PCI 2.2 slots (wake enabled devices) (Note) 375
AGP and PCI 2.2 slots (non-wake enabled devices) (Note) 20
USB ports (Note) 517.5 (max)
Optional
CNR (Note) 375
Note: Dependent upon system configuration. See the note on the following page.
✏
NOTE
AGP and PCI requirements are calculated by totaling the following:
• One wake-enabled device @ 375 mA
• Five non wake-enabled devices @ 20 mA each
PS/2 Ports requirements per the IBM PS/2 Port Specification (Sept 1991):
• Keyboard @ 275 mA (Actual measurements are 220 mA-300 mA, depending on the type of
keyboard and the operational state of the keyboard’s LEDs.)
• Mouse @ 70 mA
USB requirements are calculated by totaling the following:
• One wake-enabled device @ 500 mA
• Three USB non-wake-enabled devices @ 2.5 mA each
The USB ports are limited to a combined total of 700 mA.
CNR requirements are calculated as follows:
• One wake-enabled device @ 375 mA
• Non wake-enabled devices @ 20 mA
2.11.4 Fan Connector Current Capability
The D815EEA board is designed to supply a maximum of 225 mA per fan connector.
