Desktop Board D815EEA Technical Product Specification
62
Table 36. Wake on LAN Technology
Connector (J6B1)
Pin Signal Name
1 +5 VSB
2 Ground
3WOL
Table 37. Chassis Intrusion Connector (J7B1)
Pin Signal Name
1 INTRUDER#
2 Ground
Table 38. Chassis Fan Connector (J8B1)
Pin Signal Name
1 FAN1_PWM
2 +12 V
3 FAN1_TACH
For information about Refer to
The power connector Section 1.13.2.1, page 43
The functions of the fan connectors Section 1.13.2.2, page 43
Wake on LAN technology Section 1.13.2.3, page 44
