Intel D815EEA User Manual

Technical Reference
49
Table 13. I/O Map (continued)
Address (hex) Size Description
03F0 - 03F5 6 bytes Diskette channel 1
03F6 1 byte Primary IDE channel command port
03F8 - 03FF 8 bytes COM1
04D0 - 04D1 2 bytes Edge/level triggered PIC
One of these ranges:
0530 - 0537
0E80 - 0E87
0F40 - 0F47
8 bytes Windows Sound System
LPTn + 400 8 bytes ECP port, LPTn base address + 400h
0CF8 - 0CFB** 4 bytes PCI configuration address register
0CF9*** 1 byte Turbo and reset control register
0CFC - 0CFF 4 bytes PCI configuration data register
FFA0 - FFA7 8 bytes Primary bus master IDE registers
FFA8 - FFAF 8 bytes Secondary bus master IDE registers
96 contiguous bytes starting on a 128-byte
divisible boundary
ICH (ACPI + TCO)
64 contiguous bytes starting on a 64-byte
divisible boundary
D815EEA board resource
64 contiguous bytes starting on a 64-byte
divisible boundary
Onboard audio controller
32 contiguous bytes starting on a 32-byte
divisible boundary
ICH (USB)
16 contiguous bytes starting on a 16-byte
divisible boundary
ICH (SMBus)
4096 contiguous bytes starting on a 4096-byte
divisible boundary
Intel 82801BA PCI bridge
* Default, but can be changed to another address range.
** Dword access only
*** Byte access only
✏ NOTE
Some additional I/O addresses are not available due to ICH addresses aliassing. For information
about the ICH addressing, refer to Section 1.2 on page 16.
