C H A P T E R 5 Managing the Switch
Monitoring the VLANs on
a port
To view the VLANs on the port:
1 Right-click and select VLAN Port Monitoring.
2 Click either of the tabs to view details of that port:
RMON Interface statistics To access a range of subnet management statistics:
1 Right-click a port and select RMON Statistics.
2 This window gives more detailed information displayed as
graphs.
Tab Name
Shows the
VLAN’s...
Double-click a row
to show the...
VLAN Table in which this port is
contained
MAC addresses
learned on this port in
that specific VLAN
MAC Table MAC addresses and
IP addresses
other VLANs in
which this address is
contained
500.book Page 89 Thursday, September 2, 1999 1:30 PM
