Intel P8700 - Core 2 Duo Processor Datasheet

Electrical Specifications
26 Datasheet
3.3 Voltage Identification and Power Sequencing
The processor uses seven voltage identification pins,VID[6:0], to support automatic
selection of power supply voltages. The VID pins for the processor are CMOS outputs
driven by the processor VID circuitry. Tab l e 2 specifies the voltage level corresponding
to the state of VID[6:0]. A 1 in the table refers to a high-voltage level and a 0 refers to
a low-voltage level.
Table 2. Voltage Identification Definition (Sheet 1 of 3)
VID6 VID5 VID4 VID3 VID2 VID1 VID0 V
CC
(V)
00 00 0 0 01.5000
00 00 0 0 11.4875
00 00 0 1 01.4750
00 00 0 1 11.4625
00 00 1 0 01.4500
00 00 1 0 11.4375
00 00 1 1 01.4250
00 00 1 1 11.4125
00 01 0 0 01.4000
00 01 0 0 11.3875
00 01 0 1 01.3750
00 01 0 1 11.3625
00 01 1 0 01.3500
00 01 1 0 11.3375
00 01 1 1 01.3250
00 01 1 1 11.3125
00 10 0 0 01.3000
00 10 0 0 11.2875
00 10 0 1 01.2750
00 10 0 1 11.2625
00 10 1 0 01.2500
00 10 1 0 11.2375
00 10 1 1 01.2250
00 10 1 1 11.2125
00 11 0 0 01.2000
00 11 0 0 11.1875
00 11 0 1 01.1750
00 11 0 1 11.1625
00 11 1 0 01.1500
00 11 1 0 11.1375
00 11 1 1 01.1250
00 11 1 1 11.1125
01 00 0 0 01.1000
01 00 0 0 11.0875
01 00 0 1 01.0750
01 00 0 1 11.0625
01 00 1 0 01.0500
01 00 1 0 11.0375
01 00 1 1 01.0250
01 00 1 1 11.0125

Intel P8700 - Core 2 Duo Processor Specifications

General

Processor Number	P8700
Number of Cores	2
Threads	2
Clock Speed	2.53 GHz
Cache	3 MB L2 Cache
Bus Speed	1066 MHz
TDP	25 W
Lithography	45 nm
Socket	PGA478
Instruction Set	64-bit
Max Memory Size	8 GB
Max Memory Channels	2
Max Memory Bandwidth	17.1 GB/s
Thermal Monitoring Technologies	Yes
Execute Disable Bit	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Package Size	35mm x 35mm
Intel 64	Yes
Intel Trusted Execution Technology	No
AES New Instructions	No
Virtualization Technology	VT-x
Memory Types	DDR3
