Intel P8700 - Core 2 Duo Processor Datasheet

Datasheet 59
Package Mechanical Specifications and Pin Information
4.2 Processor Pinout and Pin List
Figure 16 and Figure 17 show the processor (SV and XE) pinout as viewed from the top
of the package. Tab le 1 6 provides the pin list, arranged numerically by pin number.
Figure 16 through Figure 18 show the top view of the LV and ULV processor package.
Tab le 1 8 lists the SFF processor ballout alphabetically by signal name. For signal
descriptions, refer to Section 4.3.
NOTES:
1. Keying option for Micro-FCPGA, A1 and B1 are de-populated.
2. Keying option for Micro-FCBGA, A1 is de-populated and B1 is VSS.
Figure 16. Processor Pinout (Top Package View, Left Side)
1 234 5 678910111213
A
1
VSS SMI# VSS FERR# A20M# VCC VSS VCC VCC VSS VCC VCC A
B
1
RSVD INIT# LINT1 DPSLP# VSS VCC VSS VCC VCC VSS VCC VSS B
C RESET# VSS TEST7
IGNNE
#
VSS LINT0
THERM
TRIP#
VSS VCC VCC VSS VCC VCC C
D VSS RSVD RSVD VSS
STPCLK
#
PWRGO
OD
SLP# VSS VCC VCC VSS VCC VSS D
E DBSY# BNR# VSS HITM#
DPRSTP
#
VSS VCC VSS VCC VCC VSS VCC VCC E
F BR0# VSS RS[0]# RS[1]# VSS RSVD VCC VSS VCC VCC VSS VCC VSS F
G VSS TRDY# RS[2]# VSS BPRI# HIT# G
H ADS#
REQ[1]
#
VSS LOCK# DEFER# VSS H
J A[9]# VSS
REQ[3]
#
A[3]# VSS VCCP J
K VSS
REQ[2]
#
REQ[0]
#
VSS A[6]# VCCP K
L REQ[4]# A[13]# VSS A[5]# A[4]# VSS L
M
ADSTB[0]
#
VSS A[7]# RSVD VSS VCCP M
N VSS A[8]# A[10]# VSS RSVD VCCP N
P A[15]# A[12]# VSS A[14]# A[11]# VSS P
R A[16]# VSS A[19]# A[24]# VSS VCCP R
T VSS RSVD A[26]# VSS A[25]# VCCP T
U A[23]# A[30]# VSS A[21]# A[18]# VSS U
V
ADSTB[1]
#
VSS RSVD A[31]# VSS VCCP V
W VSS A[27]# A[32]# VSS A[28]# A[20]# W
Y COMP[3] A[17]# VSS A[29]# A[22]# VSS
Y
AA COMP[2] VSS A[35]# A[33]# VSS TDI VCC VSS VCC VCC VSS VCC VCC
A
A
AB VSS A[34]# TDO VSS TMS TRST# VCC VSS VCC VCC VSS VCC VSS
A
B
AC PREQ# PRDY# VSS
BPM[3]
#
TCK VSS VCC VSS VCC VCC VSS VCC VCC
A
C
AD BPM[2]# VSS
BPM[1]
#
BPM[0]
#
VSS VID[0] VCC VSS VCC VCC VSS VCC VSS
A
D
AE VSS VID[6] VID[4] VSS VID[2] PSI#
VSS
SENSE
VSS VCC VCC VSS VCC VCC
A
E
AF TEST5 VSS VID[5] VID[3] VID[1] VSS
VCC
SENSE
VSS VCC VCC VSS VCC VSS
A
F
1 234 5 678910111213

Intel P8700 - Core 2 Duo Processor Specifications

General

Processor Number	P8700
Number of Cores	2
Threads	2
Clock Speed	2.53 GHz
Cache	3 MB L2 Cache
Bus Speed	1066 MHz
TDP	25 W
Lithography	45 nm
Socket	PGA478
Instruction Set	64-bit
Max Memory Size	8 GB
Max Memory Channels	2
Max Memory Bandwidth	17.1 GB/s
Thermal Monitoring Technologies	Yes
Execute Disable Bit	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Package Size	35mm x 35mm
Intel 64	Yes
Intel Trusted Execution Technology	No
AES New Instructions	No
Virtualization Technology	VT-x
Memory Types	DDR3
