Intel P8700 - Core 2 Duo Processor Datasheet

Package Mechanical Specifications and Pin Information
72 Datasheet
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
A2 VSS Power/Other
A3 SMI# CMOS Input
A4 VSS Power/Other
A5 FERR# Open Drain Output
A6 A20M# CMOS Input
A7 VCC Power/Other
A8 VSS Power/Other
A9 VCC Power/Other
A10 VCC Power/Other
A11 VSS Power/Other
A12 VCC Power/Other
A13 VCC Power/Other
A14 VSS Power/Other
A15 VCC Power/Other
A16 VSS Power/Other
A17 VCC Power/Other
A18 VCC Power/Other
A19 VSS Power/Other
A20 VCC Power/Other
A21 BCLK[1] Bus Clock Input
A22 BCLK[0] Bus Clock Input
A23 VSS Power/Other
A24 THRMDA Power/Other
A25 VSS Power/Other
A26 TEST6 Test
AA1 COMP[2] Power/Other
Input/
Output
AA2 VSS Power/Other
AA3 A[35]# Source Synch
Input/
Output
AA4 A[33]# Source Synch
Input/
Output
AA5 VSS Power/Other
AA6 TDI CMOS Input
AA7 VCC Power/Other
AA8 VSS Power/other
AA9 VCC Power/Other
AA10 VCC Power/Other
AA11 VSS Power/Other
AA12 VCC Power/Other
AA13 VCC Power/Other
AA14 VSS Power/Other
AA15 VCC Power/Other
AA16 VSS Power/Other
AA17 VCC Power/Other
AA18 VCC Power/Other
AA19 VSS Power/Other
AA20 VCC Power/Other
AA21 D[50]# Source Synch
Input/
Output
AA22 VSS Power/Other
AA23 D[45]# Source Synch
Input/
Output
AA24 D[46]# Source Synch
Input/
Output
AA25 VSS Power/Other
AA26
DSTBP[2]
#
Source Synch
Input/
Output
AB1 VSS Power/Other
AB2 A[34]# Source Synch
Input/
Output
AB3 TDO Open Drain Output
AB4 VSS Power/Other
AB5 TMS CMOS Input
AB6 TRST# CMOS Input
AB7 VCC Power/Other
AB8 VSS Power/Other
AB9 VCC Power/Other
AB10 VCC Power/Other
AB11 VSS Power/Other
AB12 VCC Power/Other
AB13 VSS Power/Other
AB14 VCC Power/Other
AB15 VCC Power/Other
AB16 VSS Power/Other
AB17 VCC Power/Other
AB18 VCC Power/Other
AB19 VSS Power/Other
AB20 VCC Power/Other
AB21 D[52]# Source Synch
Input/
Output
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
