Intel P8700 - Core 2 Duo Processor - Page 73

Package Mechanical Specifications and Pin Information
73 Datasheet
AB22 D[51]# Source Synch
Input/
Output
AB23 VSS Power/Other
AB24 D[33]# Source Synch
Input/
Output
AB25 D[47]# Source Synch
Input/
Output
AB26 VSS Power/Other
AC1 PREQ# Common Clock Input
AC2 PRDY# Common Clock Output
AC3 VSS Power/Other
AC4 BPM[3]# Common Clock
Input/
Output
AC5 TCK CMOS Input
AC6 VSS Power/Other
AC7 VCC Power/Other
AC8 VSS Power/Other
AC9 VCC Power/Other
AC10 VCC Power/Other
AC11 VSS Power/Other
AC12 VCC Power/Other
AC13 VCC Power/Other
AC14 VSS Power/Other
AC15 VCC Power/Other
AC16 VSS Power/Other
AC17 VCC Power/Other
AC18 VCC Power/Other
AC19 VSS Power/Other
AC20 DINV[3]# Source Synch
Input/
Output
AC21 VSS Power/Other
AC22 D[60]# Source Synch
Input/
Output
AC23 D[63]# Source Synch
Input/
Output
AC24 VSS Power/Other
AC25 D[57]# Source Synch
Input/
Output
AC26 D[53]# Source Synch
Input/
Output
AD1 BPM[2]# Common Clock Output
AD2 VSS Power/Other
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
AD3 BPM[1]# Common Clock Output
AD4 BPM[0]# Common Clock
Input/
Output
AD5 VSS Power/Other
AD6 VID[0] CMOS Output
AD7 VCC Power/Other
AD8 VSS Power/Other
AD9 VCC Power/Other
AD10 VCC Power/Other
AD11 VSS Power/Other
AD12 VCC Power/Other
AD13 VSS Power/Other
AD14 VCC Power/Other
AD15 VCC Power/Other
AD16 VSS Power/Other
AD17 VCC Power/Other
AD18 VCC Power/Other
AD19 VSS Power/Other
AD20 D[54]# Source Synch
Input/
Output
AD21 D[59]# Source Synch
Input/
Output
AD22 VSS Power/Other
AD23 D[61]# Source Synch
Input/
Output
AD24 D[49]# Source Synch
Input/
Output
AD25 VSS Power/Other
AD26 GTLREF Power/Other Input
AE1 VSS Power/Other
AE2 VID[6] CMOS Output
AE3 VID[4] CMOS Output
AE4 VSS Power/Other
AE5 VID[2] CMOS Output
AE6 PSI# CMOS Output
AE7 VSSSENSE Power/Other Output
AE8 VSS Power/Other
AE9 VCC Power/Other
AE10 VCC Power/Other
AE11 VSS Power/Other
AE12 VCC Power/Other
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
