Intel P8700 - Core 2 Duo Processor Datasheet

Package Mechanical Specifications and Pin Information
Datasheet 74
AE13 VCC Power/Other
AE14 VSS Power/Other
AE15 VCC Power/Other
AE16 VSS Power/Other
AE17 VCC Power/Other
AE18 VCC Power/Other
AE19 VSS Power/Other
AE20 VCC Power/Other
AE21 D[58]# Source Synch
Input/
Output
AE22 D[55]# Source Synch
Input/
Output
AE23 VSS Power/Other
AE24 D[48]# Source Synch
Input/
Output
AE25
DSTBN[3]
#
Source Synch
Input/
Output
AE26 VSS Power/Other
AF1 TEST5 Test
AF2 VSS Power/Other
AF3 VID[5] CMOS Output
AF4 VID[3] CMOS Output
AF5 VID[1] CMOS Output
AF6 VSS Power/Other
AF7
VCCSENS
E
Power/Other
AF8 VSS Power/Other
AF9 VCC Power/Other
AF10 VCC Power/Other
AF11 VSS Power/Other
AF12 VCC Power/Other
AF13 VSS Power/Other
AF14 VCC Power/Other
AF15 VCC Power/Other
AF16 VSS Power/Other
AF17 VCC Power/Other
AF18 VCC Power/Other
AF19 VSS Power/Other
AF20 VCC Power/Other
AF21 VSS Power/Other
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
AF22 D[62]# Source Synch
Input/
Output
AF23 D[56]# Source Synch
Input/
Output
AF24
DSTBP[3]
#
Source Synch
Input/
Output
AF25 VSS Power/Other
AF26 TEST4 Test
B2 RSVD Reserved
B3 INIT# CMOS Input
B4 LINT1 CMOS Input
B5 DPSLP# CMOS Input
B6 VSS Power/Other
B7 VCC Power/Other
B8 VSS Power/Other
B9 VCC Power/Other
B10 VCC Power/Other
B11 VSS Power/Other
B12 VCC Power/Other
B13 VSS Power/Other
B14 VCC Power/Other
B15 VCC Power/Other
B16 VSS Power/Other
B17 VCC Power/Other
B18 VCC Power/Other
B19 VSS Power/Other
B20 VCC Power/Other
B21 VSS Power/Other
B22 BSEL[0] CMOS Output
B23 BSEL[1] CMOS Output
B24 VSS Power/Other
B25 THRMDC Power/Other
B26 VCCA Power/Other
C1 RESET# Common Clock Input
C2 VSS Power/Other
C3 TEST7 Test
C4 IGNNE# CMOS Input
C5 VSS Power/Other
C6 LINT0 CMOS Input
C7
THERMTRI
P#
Open Drain Output
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
