Intel P8700 - Core 2 Duo Processor - Pin Name Listing

Package Mechanical Specifications and Pin Information
Datasheet 61
Table 16. Pin Name Listing
Pin Name Pin #
Signal
Buffer
Type
Direction
A[3]# J4
Source
Synch
Input/
Output
A[4]# L5
Source
Synch
Input/
Output
A[5]# L4
Source
Synch
Input/
Output
A[6]# K5
Source
Synch
Input/
Output
A[7]# M3
Source
Synch
Input/
Output
A[8]# N2
Source
Synch
Input/
Output
A[9]# J1
Source
Synch
Input/
Output
A[10]# N3
Source
Synch
Input/
Output
A[11]# P5
Source
Synch
Input/
Output
A[12]# P2
Source
Synch
Input/
Output
A[13]# L2
Source
Synch
Input/
Output
A[14]# P4
Source
Synch
Input/
Output
A[15]# P1
Source
Synch
Input/
Output
A[16]# R1
Source
Synch
Input/
Output
A[17]# Y2
Source
Synch
Input/
Output
A[18]# U5
Source
Synch
Input/
Output
A[19]# R3
Source
Synch
Input/
Output
A[20]# W6
Source
Synch
Input/
Output
A[21]# U4
Source
Synch
Input/
Output
A[22]# Y5
Source
Synch
Input/
Output
A[23]# U1
Source
Synch
Input/
Output
A[24]# R4
Source
Synch
Input/
Output
A[25]# T5
Source
Synch
Input/
Output
A[26]# T3
Source
Synch
Input/
Output
A[27]# W2
Source
Synch
Input/
Output
A[28]# W5
Source
Synch
Input/
Output
A[29]# Y4
Source
Synch
Input/
Output
A[30]# U2
Source
Synch
Input/
Output
A[31]# V4
Source
Synch
Input/
Output
A[32]# W3
Source
Synch
Input/
Output
A[33]# AA4
Source
Synch
Input/
Output
A[34]# AB2
Source
Synch
Input/
Output
A[35]# AA3
Source
Synch
Input/
Output
A20M# A6 CMOS Input
ADS# H1
Common
Clock
Input/
Output
ADSTB[0]# M1
Source
Synch
Input/
Output
ADSTB[1]# V1
Source
Synch
Input/
Output
BCLK[0] A22 Bus Clock Input
BCLK[1] A21 Bus Clock Input
BNR# E2
Common
Clock
Input/
Output
BPM[0]# AD4
Common
Clock
Input/
Output
BPM[1]# AD3
Common
Clock
Output
BPM[2]# AD1
Common
Clock
Output
BPM[3]# AC4
Common
Clock
Input/
Output
Table 16. Pin Name Listing
Pin Name Pin #
Signal
Buffer
Type
Direction
