Intel P8700 - Core 2 Duo Processor Datasheet

6 Datasheet
Revision History
§
Document
Number
Revision
Number
Description Date
320120 -001 Initial Release July 2008
320120 -002
• Chapter Update
— Chapter 1: Added introduction to the Intel Core 2 Duo
Processor in SFF Package
— Section 4.1: Added the package coplanarity information for
the processors in SFF Package
• Figure Update
— Added Figure 7
— Added Figure 8
— Added Figure 14
— Added Figure 15
— Added Figure 18 through Figure 21
• Table Update
— Added Table 9
— Added Table 10
— Added Table 11
— Added Table 12
— Updated Tabl e 1 6 : Added Intel Core 2 Duo SFF Package
Processor Ball listing by Pin name
— Added Table 18
— Added Table 23
— Added Table 24
— Added Table 25
August 2008
320120 -003
• Added information for Intel Core 2 Duo T9800, T9550, P9600,
P8700
January 2009
320120 -004
• Added information for Intel Core 2 Duo processor skus below:
— Updated Table 7 and 21 with T9900
— Updated Table 9 and 23 with SP9600
— Updated Table 10 and 24 with SL9600
— Updataed Table 11 and 25 with SU9600
— Updated Table 12 and 26 with SU3500
March 2009

Intel P8700 - Core 2 Duo Processor Specifications

General

Processor Number	P8700
Number of Cores	2
Threads	2
Clock Speed	2.53 GHz
Cache	3 MB L2 Cache
Bus Speed	1066 MHz
TDP	25 W
Lithography	45 nm
Socket	PGA478
Instruction Set	64-bit
Max Memory Size	8 GB
Max Memory Channels	2
Max Memory Bandwidth	17.1 GB/s
Thermal Monitoring Technologies	Yes
Execute Disable Bit	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Package Size	35mm x 35mm
Intel 64	Yes
Intel Trusted Execution Technology	No
AES New Instructions	No
Virtualization Technology	VT-x
Memory Types	DDR3
