Intel P8700 - Core 2 Duo Processor - Page 63

Package Mechanical Specifications and Pin Information
Datasheet 63
D[36]# V23
Source
Synch
Input/
Output
D[37]# T22
Source
Synch
Input/
Output
D[38]# U25
Source
Synch
Input/
Output
D[39]# U23
Source
Synch
Input/
Output
D[40]# Y25
Source
Synch
Input/
Output
D[41]# W22
Source
Synch
Input/
Output
D[42]# Y23
Source
Synch
Input/
Output
D[43]# W24
Source
Synch
Input/
Output
D[44]# W25
Source
Synch
Input/
Output
D[45]# AA23
Source
Synch
Input/
Output
D[46]# AA24
Source
Synch
Input/
Output
D[47]# AB25
Source
Synch
Input/
Output
D[48]# AE24
Source
Synch
Input/
Output
D[49]# AD24
Source
Synch
Input/
Output
D[50]# AA21
Source
Synch
Input/
Output
D[51]# AB22
Source
Synch
Input/
Output
D[52]# AB21
Source
Synch
Input/
Output
D[53]# AC26
Source
Synch
Input/
Output
D[54]# AD20
Source
Synch
Input/
Output
D[55]# AE22
Source
Synch
Input/
Output
D[56]# AF23
Source
Synch
Input/
Output
D[57]# AC25
Source
Synch
Input/
Output
Table 16. Pin Name Listing
Pin Name Pin #
Signal
Buffer
Type
Direction
D[58]# AE21
Source
Synch
Input/
Output
D[59]# AD21
Source
Synch
Input/
Output
D[60]# AC22
Source
Synch
Input/
Output
D[61]# AD23
Source
Synch
Input/
Output
D[62]# AF22
Source
Synch
Input/
Output
D[63]# AC23
Source
Synch
Input/
Output
DBR# C20 CMOS Output
DBSY# E1
Common
Clock
Input/
Output
DEFER# H5
Common
Clock
Input
DINV[0]# H25
Source
Synch
Input/
Output
DINV[1]# N24
Source
Synch
Input/
Output
DINV[2]# U22
Source
Synch
Input/
Output
DINV[3]# AC20
Source
Synch
Input/
Output
DPRSTP# E5 CMOS Input
DPSLP# B5 CMOS Input
DPWR# D24
Common
Clock
Input/
Output
DRDY# F21
Common
Clock
Input/
Output
DSTBN[0]# J26
Source
Synch
Input/
Output
DSTBN[1]# L26
Source
Synch
Input/
Output
DSTBN[2]# Y26
Source
Synch
Input/
Output
DSTBN[3]# AE25
Source
Synch
Input/
Output
DSTBP[0]# H26
Source
Synch
Input/
Output
DSTBP[1]# M26
Source
Synch
Input/
Output
Table 16. Pin Name Listing
Pin Name Pin #
Signal
Buffer
Type
Direction
