Package Mechanical Specifications and Pin Information
Datasheet 79
W24 D[43]# Source Synch
Input/
Output
W25 D[44]# Source Synch
Input/
Output
W26 VSS Power/Other
Y1 COMP[3] Power/Other
Input/
Output
Y2 A[17]# Source Synch
Input/
Output
Y3 VSS Power/Other
Y4 A[29]# Source Synch
Input/
Output
Y5 A[22]# Source Synch
Input/
Output
Y6 VSS Power/Other
Y21 VSS Power/Other
Y22 D[32]# Source Synch
Input/
Output
Y23 D[42]# Source Synch
Input/
Output
Y24 VSS Power/Other
Y25 D[40]# Source Synch
Input/
Output
Y26
DSTBN[2]
#
Source Synch
Input/
Output
Table 17. Pin # Listing
Pin # Pin Name
Signal Buffer
Type
Directi
on
