Intel P8700 - Core 2 Duo Processor Datasheet

Datasheet 85
Package Mechanical Specifications and Pin Information
D[56]# AY36 PRDY# AV10 TMS AW5
D[57]# AT40 PREQ# AV2 TRDY# L1
D[58]# BC35 PROCHOT# D38 TRST# AV8
D[59]# BC39 PSI# BD10 VCC AA33
D[60]# BA41 PWRGOOD E7 VCC AB16
D[61]# BB40 REQ[0]# R1 VCC AB18
D[62]# BA35 REQ[1]# R5 VCC AB20
D[63]# AU43 REQ[2]# U1 VCC AB22
DBR# J7 REQ[3]# P4 VCC AB24
DBSY# J1 REQ[4]# W5 VCC AB26
DEFER# N5 RESET# G5 VCC AB28
DINV[0]# P40 RS[0]# K2 VCC AB30
DINV[1]# R43 RS[1]# H4 VCC AB32
DINV[2]# AJ41 RS[2]# K4 VCC AC33
DINV[3]# BC37 RSVD01 V2 VCC AD16
DPRSTP# G7 RSVD02 Y2 VCC AD18
DPSLP# B8 RSVD03 AG5 VCC AD20
DPWR# C41 RSVD04 AL5 VCC AD22
DRDY# F38 RSVD05 J9 VCC AD24
DSTBN[0]# K40 RSVD06 F4 VCC AD26
DSTBN[1]# U43 RSVD07 H8 VCC AD28
DSTBN[2]# AK44 SLP# D10 VCC AD30
DSTBN[3]# AY40 SMI# E5 VCC AD32
DSTBP[0]# J41 STPCLK# F8 VCC AE33
DSTBP[1]# W43 TCK AV4 VCC AF16
DSTBP[2]# AL43 TDI AW7 VCC AF18
DSTBP[3]# AY38 TDO AU1 VCC AF20
FERR# D4 TEST1 E37 VCC AF22
GTLREF AW43 TEST2 D40 VCC AF24
HIT# H2 TEST3 C43 VCC AF26
HITM# F2 TEST4 AE41 VCC AF28
IERR# B40 TEST5 AY10 VCC AF30
IGNNE# F10 TEST6 AC43 VCC AF32
INIT# D8 THERMTRIP# B10 VCC AG33
LINT0 C9 THRMDA BB34 VCC AH16
LINT1 C5 THRMDC BD34 VCC AH18
LOCK# N1 THERMTRIP# B10 VCC AH20
Table 18.Intel Core 2 Duo Mobile Processor in SFF Package Listing by Ball Name
Signal
Name
Ball
Number
Signal Name
Ball
Number
Signal
Name
Ball
Number

Intel P8700 - Core 2 Duo Processor Specifications

General

Processor Number	P8700
Number of Cores	2
Threads	2
Clock Speed	2.53 GHz
Cache	3 MB L2 Cache
Bus Speed	1066 MHz
TDP	25 W
Lithography	45 nm
Socket	PGA478
Instruction Set	64-bit
Max Memory Size	8 GB
Max Memory Channels	2
Max Memory Bandwidth	17.1 GB/s
Thermal Monitoring Technologies	Yes
Execute Disable Bit	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Package Size	35mm x 35mm
Intel 64	Yes
Intel Trusted Execution Technology	No
AES New Instructions	No
Virtualization Technology	VT-x
Memory Types	DDR3
