Intel P8700 - Core 2 Duo Processor Datasheet

Datasheet 87
Package Mechanical Specifications and Pin Information
VCC F24 VCC P18 VCC Y32
VCC F26 VCC P20 VCCA B34
VCC F28 VCC P22 VCCA D34
VCC F30 VCC P24 VCCP A13
VCC F32 VCC P26 VCCP A33
VCC G33 VCC P28 VCCP AA7
VCC H16 VCC P30 VCCP AA9
VCC H18 VCC P32 VCCP AA11
VCC H20 VCC R33 VCCP AA13
VCC H22 VCC T16 VCCP AA35
VCC H24 VCC T18 VCCP AA37
VCC H26 VCC T20 VCCP AB10
VCC H28 VCC T22 VCCP AB12
VCC H30 VCC T24 VCCP AB14
VCC H32 VCC T26 VCCP AB36
VCC J33 VCC T28 VCCP AB38
VCC K16 VCC T30 VCCP AC7
VCC K18 VCC T32 VCCP AC9
VCC K20 VCC U33 VCCP AC11
VCC K22 VCC V16 VCCP AC13
VCC K24 VCC V18 VCCP AC35
VCC K26 VCC V20 VCCP AC37
VCC K28 VCC V22 VCCP AD14
VCC K30 VCC V24 VCCP AE7
VCC K32 VCC V26 VCCP AE9
VCC L33 VCC V28 VCCP AE11
VCC M16 VCC V30 VCCP AE13
VCC M18 VCC V32 VCCP AE35
VCC M20 VCC W33 VCCP AE37
VCC M22 VCC Y16 VCCP AF10
VCC M24 VCC Y18 VCCP AF12
VCC M26 VCC Y20 VCCP AF14
VCC M28 VCC Y22 VCCP AF36
VCC M30 VCC Y24 VCCP AF38
VCC M32 VCC Y26 VCCP AG7
VCC N33 VCC Y28 VCCP AG9
VCC P16 VCC Y30 VCCP AG11
Table 18.Intel Core 2 Duo Mobile Processor in SFF Package Listing by Ball Name
Signal
Name
Ball
Number
Signal Name
Ball
Number
Signal
Name
Ball
Number

Intel P8700 - Core 2 Duo Processor Specifications

General

Processor Number	P8700
Number of Cores	2
Threads	2
Clock Speed	2.53 GHz
Cache	3 MB L2 Cache
Bus Speed	1066 MHz
TDP	25 W
Lithography	45 nm
Socket	PGA478
Instruction Set	64-bit
Max Memory Size	8 GB
Max Memory Channels	2
Max Memory Bandwidth	17.1 GB/s
Thermal Monitoring Technologies	Yes
Execute Disable Bit	Yes
Idle States	Yes
Enhanced Intel SpeedStep Technology	Yes
Package Size	35mm x 35mm
Intel 64	Yes
Intel Trusted Execution Technology	No
AES New Instructions	No
Virtualization Technology	VT-x
Memory Types	DDR3
