Land Listing
72 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
AJ8 VCC Power/Other
AJ9 VCC Power/Other
AK1 RESERVED
AK10 VSS Power/Other
AK11 VCC Power/Other
AK12 VCC Power/Other
AK13 VSS Power/Other
AK14 VCC Power/Other
AK15 VCC Power/Other
AK16 VSS Power/Other
AK17 VSS Power/Other
AK18 VCC Power/Other
AK19 VCC Power/Other
AK2 VSS Power/Other
AK20 VSS Power/Other
AK21 VCC Power/Other
AK22 VCC Power/Other
AK23 VSS Power/Other
AK24 VSS Power/Other
AK25 VCC Power/Other
AK26 VCC Power/Other
AK27 VSS Power/Other
AK28 VSS Power/Other
AK29 VSS Power/Other
AK3 RESERVED
AK30 VSS Power/Other
AK4 VID4 Power/Other Output
AK5 VSS Power/Other
AK6 FORCEPR# CMOS
Asynchronous
Input
AK7 VSS Power/Other
AK8 VCC Power/Other
AK9 VCC Power/Other
AL1 RESERVED
AL10 VSS Power/Other
AL11 VCC Power/Other
AL12 VCC Power/Other
AL13 VSS Power/Other
AL14 VCC Power/Other
AL15 VCC Power/Other
AL16 VSS Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 7 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
AL17 VSS Power/Other
AL18 VCC Power/Other
AL19 VCC Power/Other
AL2 PROCHOT# Open Drain
Asynchronous
Output
AL20 VSS Power/Other
AL21 VCC Power/Other
AL22 VCC Power/Other
AL23 VSS Power/Other
AL24 VSS Power/Other
AL25 VCC Power/Other
AL26 VCC Power/Other
AL27 VSS Power/Other
AL28 VSS Power/Other
AL29 VCC Power/Other
AL3 VSS Power/Other
AL30 VCC Power/Other
AL4 VID5 Power/Other Output
AL5 VID1 Power/Other Output
AL6 VID3 Power/Other Output
AL7 VSS_DIE_SENSE2 Power/Other
AL8 VCC_DIE_SENSE2 Power/Other
AL9 VCC Power/Other
AM1 VSS Power/Other
AM10 VSS Power/Other
AM11 VCC Power/Other
AM12 VCC Power/Other
AM13 VSS Power/Other
AM14 VCC Power/Other
AM15 VCC Power/Other
AM16 VSS Power/Other
AM17 VSS Power/Other
AM18 VCC Power/Other
AM19 VCC Power/Other
AM2 RESERVED
AM20 VSS Power/Other
AM21 VCC Power/Other
AM22 VCC Power/Other
AM23 VSS Power/Other
AM24 VSS Power/Other
AM25 VCC Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 8 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
