Quad-Core Intel® Xeon® Processor 5300 Series Datasheet 73
Land Listing
AM26 VCC Power/Other
AM27 VSS Power/Other
AM28 VSS Power/Other
AM29 VCC Power/Other
AM3 VID2 Power/Other Output
AM30 VCC Power/Other
AM4 VSS Power/Other
AM5 VID6 Power/Other Output
AM6 RESERVED
AM7 VSS Power/Other
AM8 VCC Power/Other
AM9 VCC Power/Other
AN1 VSS Power/Other
AN10 VSS Power/Other
AN11 VCC Power/Other
AN12 VCC Power/Other
AN13 VSS Power/Other
AN14 VCC Power/Other
AN15 VCC Power/Other
AN16 VSS Power/Other
AN17 VSS Power/Other
AN18 VCC Power/Other
AN19 VCC Power/Other
AN2 VSS Power/Other
AN20 VSS Power/Other
AN21 VCC Power/Other
AN22 VCC Power/Other
AN23 VSS Power/Other
AN24 VSS Power/Other
AN25 VCC Power/Other
AN26 VCC Power/Other
AN3 VCC_DIE_SENSE Power/Other Output
AN4 VSS_DIE_SENSE Power/Other Output
AN5 RESERVED
AN6 RESERVED
AN7 VID_SELECT Power/Other Output
AN8 VCC Power/Other
AN9 VCC Power/Other
B1 VSS Power/Other
B10 D10# Source Sync Input/Output
Table 4-2. Land Listing by Land Number
(Sheet 9 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
B11 VSS Power/Other
B12 D13# Source Sync Input/Output
B13 RESERVED
B14 VSS Power/Other
B15 D53# Source Sync Input/Output
B16 D55# Source Sync Input/Output
B17 VSS Power/Other
B18 D57# Source Sync Input/Output
B19 D60# Source Sync Input/Output
B2 DBSY# Common Clk Input/Output
B20 VSS Power/Other
B21 D59# Source Sync Input/Output
B22 D63# Source Sync Input/Output
B23 RESERVED
B24 VSS Power/Other
B25 VTT Power/Other
B26 VTT Power/Other
B27 VTT Power/Other
B28 VTT Power/Other
B29 VTT Power/Other
B3 RS0# Common Clk Input
B30 VTT Power/Other
B4 D00# Source Sync Input/Output
B5 VSS Power/Other
B6 D05# Source Sync Input/Output
B7 D06# Source Sync Input/Output
B8 VSS Power/Other
B9 DSTBP0# Source Sync Input/Output
C1 DRDY# Common Clk Input/Output
C10 VSS Power/Other
C11 D11# Source Sync Input/Output
C12 D14# Source Sync Input/Output
C13 VSS Power/Other
C14 D52# Source Sync Input/Output
C15 D51# Source Sync Input/Output
C16 VSS Power/Other
C17 DSTBP3# Source Sync Input/Output
C18 D54# Source Sync Input/Output
C19 VSS Power/Other
C2 BNR# Common Clk Input/Output
Table 4-2. Land Listing by Land Number
(Sheet 10 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
