Land Listing
74 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
C20 DBI3# Source Sync Input/Output
C21 D58# Source Sync Input/Output
C22 VSS Power/Other
C23 RESERVED
C24 VSS Power/Other
C25 VTT Power/Other
C26 VTT Power/Other
C27 VTT Power/Other
C28 VTT Power/Other
C29 VTT Power/Other
C3 LOCK# Common Clk Input/Output
C30 VTT Power/Other
C4 VSS Power/Other
C5 D01# Source Sync Input/Output
C6 D03# Source Sync Input/Output
C7 VSS Power/Other
C8 DSTBN0# Source Sync Input/Output
C9 BPMb1# Common Clk Output
D1 RESERVED
D10 D22# Source Sync Input/Output
D11 D15# Source Sync Input/Output
D12 VSS Power/Other
D13 D25# Source Sync Input/Output
D14 RESERVED
D15 VSS Power/Other
D16 RESERVED
D17 D49# Source Sync Input/Output
D18 VSS Power/Other
D19 DBI2# Source Sync Input/Output
D2 ADS# Common Clk Input/Output
D20 D48# Source Sync Input/Output
D21 VSS Power/Other
D22 D46# Source Sync Input/Output
D23 VCCPLL Power/Other Input
D24 VSS Power/Other
D25 VTT Power/Other
D26 VTT Power/Other
D27 VTT Power/Other
D28 VTT Power/Other
D29 VTT Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 11 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
D3 VSS Power/Other
D30 VTT Power/Other
D4 HIT# Common Clk Input/Output
D5 VSS Power/Other
D6 VSS Power/Other
D7 D20# Source Sync Input/Output
D8 D12# Source Sync Input/Output
D9 VSS Power/Other
E1 RESERVED Power/Other
E10 D21# Source Sync Input/Output
E11 VSS Power/Other
E12 DSTBP1# Source Sync Input/Output
E13 D26# Source Sync Input/Output
E14 VSS Power/Other
E15 D33# Source Sync Input/Output
E16 D34# Source Sync Input/Output
E17 VSS Power/Other
E18 D39# Source Sync Input/Output
E19 D40# Source Sync Input/Output
E2 VSS Power/Other
E20 VSS Power/Other
E21 D42# Source Sync Input/Output
E22 D45# Source Sync Input/Output
E23 RESERVED
E24 RESERVED
E25 VSS Power/Other
E26 VSS Power/Other
E27 VSS Power/Other
E28 VSS Power/Other
E29 RESERVED
E3 TRDY# Common Clk Input
E30 VTT Power/Other
E4 HITM# Common Clk Input/Output
E5 RESERVED
E6 RESERVED
E7 RESERVED
E8 VSS Power/Other
E9 D19# Source Sync Input/Output
F1 VSS Power/Other
F10 VSS Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 12 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
