Land Listing
78 Quad-Core Intel® Xeon® Processor 5300 Series Datasheet
§
U25 VCC Power/Other
U26 VCC Power/Other
U27 VCC Power/Other
U28 VCC Power/Other
U29 VCC Power/Other
U3 AP1# Common Clk Input/Output
U30 VCC Power/Other
U4 A13# Source Sync Input/Output
U5 A12# Source Sync Input/Output
U6 A10# Source Sync Input/Output
U7 VSS Power/Other
U8 VCC Power/Other
V1 MS_ID1 Power/Other Output
V2 LL_ID0 Power/Other Output
V23 VSS Power/Other
V24 VSS Power/Other
V25 VSS Power/Other
V26 VSS Power/Other
V27 VSS Power/Other
V28 VSS Power/Other
V29 VSS Power/Other
V3 VSS Power/Other
V30 VSS Power/Other
V4 A15# Source Sync Input/Output
V5 A14# Source Sync Input/Output
V6 VSS Power/Other
V7 VSS Power/Other
V8 VCC Power/Other
W1 MS_ID0 Power/Other Output
W2 TESTIN1 Power/Other Input
W23 VCC Power/Other
W24 VCC Power/Other
W25 VCC Power/Other
W26 VCC Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 19 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
W27 VCC Power/Other
W28 VCC Power/Other
W29 VCC Power/Other
W3 TESTHI01 Power/Other Input
W30 VCC Power/Other
W4 VSS Power/Other
W5 A16# Source Sync Input/Output
W6 A18# Source Sync Input/Output
W7 VSS Power/Other
W8 VCC Power/Other
Y1 RESERVED
Y2 VSS Power/Other
Y23 VCC Power/Other
Y24 VCC Power/Other
Y25 VCC Power/Other
Y26 VCC Power/Other
Y27 VCC Power/Other
Y28 VCC Power/Other
Y29 VCC Power/Other
Y3 RESERVED
Y30 VCC Power/Other
Y4 A20# Source Sync Input/Output
Y5 VSS Power/Other
Y6 A19# Source Sync Input/Output
Y7 VSS Power/Other
Y8 VCC Power/Other
Table 4-2. Land Listing by Land Number
(Sheet 20 of 20)
Pin
No.
Pin Name
Signal
Buffer Type
Direction
