Appendix B: Integrated BMC Sensor Tables Intel® Server Board S2400SC TPS
Intel order number G36516-002 Revision 2.0
120
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Reading
Type
Event Offset Triggers
Contrib. To
System Status
Assert/De-
assert
Readable
Value/Off
sets
Event
Data
Rearm
Stand-
by
IO Module Presence
(IO Mod Presence)
0Eh
Platform-
specific
Module/Boa
rd
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As and
De
–
Trig
Offset
M -
SAS Module Presence
(SAS Mod Presence)
0Fh
Platform-
specific
Module/Boa
rd
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As and
De
–
Trig
Offset
M X
BMC Firmware Health
(BMC FW Health)
10h All
Mgmt
Health
28h
Sensor
Specific
6Fh
04 – Sensor Failure
Degraded
As -
Trig
Offset
A X
System Airflow
(System Airflow)
11h All
Other Units
0Bh
Threshold
01h
– – – Analog – – –
FW Update Status
12h
All
Version
Change
2Bh
OEM defined
x70h
00h

Update started
01hUpdate
completed
successfully.
02hUpdate failure
OK
As
_
Trig
Offset
A
_
IO Module2 Presence
(IO Mod2 Presence)
13h
Platform-
specific
Module/Boa
rd
15h
Digital
Discrete
08h
01 – Inserted/Present OK
As and
De
–
Trig
Offset
M -
Baseboard Temperature 5
(Platform Specific)
14h
Platform-
specific
Temperatur
e
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A X
Baseboard Temperature 6
(Platform Specific)
15h
Platform-
specific
Temperatur
e
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A X
IO Module2 Temperature
(I/O Mod2 Temp)
16h
Platform-
specific
Temperatur
e
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A X
PCI Riser 3 Temperature
(PCI Riser 5 Temp)
17h
Platform-
specific
Temperatur
e
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As and
De
Analog R, T A X
