Appendix B: Integrated BMC Sensor Tables Intel® Server Board S3420GP TPS
Revision 2.4
Intel order number E65697-010
116
Sensor Name
3
Sensor # Platform
Applicability
Sensor Type Event /
Reading
Type
Event Offset
Triggers
Contrib. To
System
Status
Assert /
De-
assert
Readable
Value /
Offsets
Event
Data
Rearm Stand-
by
BB +1.1V P1 Vccp 11h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A –
BB +1.1V P2 Vccp 12h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A –
BB +1.5V P1 DDR3 13h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A –
BB +1.5V P2 DDR3 14h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A –
BB +1.8V AUX 15h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A X
BB +3.3V 16h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A –
BB +3.3V STBY 17h All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-
fatal
As and
De
Analog R, T A X
BB Vbat 18h All
Voltage
02h
Generic
05h
01 - Limit
exceeded
Non-fatal
As and
De
– Trig Offset A X
