Overview Intel® Server Board S3420GP TPS
Revision 2.4
Intel order number E65697-010
14
2.2.3 Server Board Rear I/O Layout
The following figure shows the layout of the rear I/O components for the server board.
A Serial Port A C NIC Port 1 (1 Gb) and Dual USB Port
Connector
B Video D NIC port 2 (1 Gb) and Dual USB Port
Connector
Figure 9. Intel
®
Server Board S3420GP Rear I/O Layout
