BIOS User Interface Intel® Server Board S3420GP TPS
Revision 2.4
Intel order number E65697-010
58
Advanced
Mass Storage Controller Configuration
Intel
®
Entry SAS RAID Module Enabled/Disabled
Configure Intel
®
Entry SAS RAID Module LSI
®
Integrated RAID/Intel
®
ESRTII
Onboard SATA Controller Enabled/Disabled
Configure SATA Mode ENHANCED/COMPATIBILITY/AHCI/SW RAID
► SATA Port 0 Not Installed/<Drive Info.>
► SATA Port 1 Not Installed/<Drive Info.>
► SATA Port 2 Not Installed/<Drive Info.>
► SATA Port 3 Not Installed/<Drive Info.>
► SATA Port 4 Not Installed/<Drive Info.>
► SATA Port 5 Not Installed/<Drive Info.>
Figure 23. Setup Utility – Mass Storage Controller Configuration Screen Display
Table 22. Setup Utility – Mass Storage Controller Configuration Screen Fields
Setup Item Options Help Text Comments
Intel
®
Entry SAS RAID
Module
Enabled
Disabled
Enabled or Disable the Intel
®
SAS
Entry RAID Module
Unavailable if the SAS Module
(AXX4SASMOD) is not present.
Note: This option is not
available on some models.
Configure Intel
®
Entry
SAS RAID Module
LSI
®
Integrated
RAID
Intel
®
ESRTII
LSI
®
Integrated RAID - Supports
RAID 0, RAID 1, and RAID 1e, as
well as IT (JBOD) mode;
Intel
®
ESRTII - Intel
®
Embedded
Server RAID Technology II, which
supports RAID 0, RAID 1, RAID
10.
Unavailable if the SAS Module
(AXX4SASMOD) is disabled or
not present
Note: This option is not
available on some models.
Onboard SATA
Controller
Enabled
Disabled
Onboard Serial ATA (SATA)
controller.
SATA Mode ENHANCED
COMPATIBILITY
AHCI
Intel ESRT2
Matrix RAID
[ENHANCED] - Supports up to 6
SATA ports with IDE Native
Mode.
[COMPATIBILITY] - Supports up
to 4 SATA ports[0/1/2/3] with IDE
Legacy mode and 2 SATA
ports[4/5] with IDE Native Mode.
[AHCI] - Supports all SATA ports
using the Advanced Host
Controller Interface.
[Intel ESRT2] - Supports RAID
0/1/10 with Intel
®
Embedded
Software RAIDII Technology.
[Matrix RAID] – Supports RAID
levels 0/1/10 and 5 with Intel
®
Matrix Storage RAID Technology.
Disappears when the Onboard
SATA Controller is disabled.
