Intel® Server Board S3420GP TPS Server Management Capability for Intel® Server Board S3420GPV
Revision 2.4
Intel order number E65697-010
43

Main
Advanc
ed
Secu rit
y
Server
Management
Boot
Options
Boot Manager

Hardware monitor
Real-time Temperature and Voltage Status
Fan Controller Manual
CPU Fan
Hysteresis
Default Fan PW M
[2 Degree Celsius/3 Degree Celsius/4 Degree Celsius
[40%/60%/80%/100%]
System Fan
Hysteresis
Default Fan PWM
[2 Degree Celsius/3 Degree Celsius/4 Degree Celsius
[40%/60%/80%/100%]
Auxiliary Fan 1
Hysteresis
Default Fan PWM
[2 Degree Celsius/3 Degree Celsius/4 Degree Celsius
[40%/60%/80%/100%]
Auxiliary Fan 2
Hysteresis
Default Fan PWM
[2 Degree Celsius/3 Degree Celsius/4 Degree Celsius
[40%/60%/80%/100%]
Figure 16. Setup Utility — Fan controller (Manual) Display
Table 14. Setup Utility — Hardware Monitor Screen Fields
Setup Item Options Help Text Comments
Voltage and
Temperature Status
display monitored voltage, current
Fan speed PWM and temperature
CPU Fan Controller Auto
Manual
CPU temperature control policy
Auto - Fan speed control setting by
default
Manual - user adjust Fan speed
control setting value manually
