Intel® Server Board S3420GP TPS Overview
Revision 2.4
Intel order number E65697-010
7
Table 2. Major Board Components
Description Description
A Slot 1, 32 Mbit/33 MHz PCI Q System FAN2 and System FAN 3
B Slot 2, PCI Express* Gen1 x1 (x4 connector)
(Intel Server Board S3420GPLX only)
R CPU connector
C Intel RMM3 Connector(Intel Server Board
S3420GPLX only)
S CPU Fan connector
D Slot 3, PCI Express* Gen1 x4 (PCI Express*
Gen2 compliant)
T USB SSD connector (Intel
®
Server Board
S3420GPLX and S3420GPLC)
E Slot 4, PCI Express* Gen2 x4 (x8 connector)
(x8 connector)( Intel
®
Server Board S3420GPLX
only)
U 50-pin PCI Express* connector (Intel
®
Server Board
S3420GPLX only)
F Slot 5. PCI Express* Gen2 x8 (x8 connector) V System FAN 1 (Intel
®
Server Board S3420GPLX
and S3420GPLC)
G Slot 6, PCI Express* Gen2 x8 (x16 connector) W IPMB(Intel
®
Server Board S3420GPLX and
S3420GPLC)
H CMOS battery X SATA_SGPIO
I Ethernet and Dual USB COMBO Y HSBP (Intel
®
Server Board S3420GPLX and
S3420GPLC)
J Ethernet and Dual USB COMBO Z USB Floppy (Intel
®
Server Board S3420GPLX and
S3420GPLC)
K System FAN 4 AA Six SATA ports
L Video port BB Internal USB Connector ( One for Internal USB
header on Intel
®
Server Board S3420GPV)
M External Serial port CC Front Panel Connector
N Main Power Connector DD Internal Serial Port (Intel
®
Server Board S3420GPLX
and S3420GPLC)
O CPU Power connector
P DIMM slots (4 slots on Intel
®
Server Board
S3420GPV)
