Functional Architecture Intel® Server Board S3420GP TPS
Revision 2.4
Intel order number E65697-010
24
3.2.4.6 RDIMM Configuration rules
DIMM slots per channel DIMMs populated per channel Speed Ranks per channel
3 1 1066, 1333 Single Rank, Dual Rank
3 1 1066 Quad Rank
3 2 1066, 1333 Single Rank, Dual Rank
3 2 800* Quad Rank
3 3** 800* Single Rank, Dual Rank
Table 7. RDIMM memory configuration rule
To get the maximum memory size on RDIMM, refer to the following table:
Max Memory Possible 1Gb DRAM Technology 2Gb DRAM Technology
Single Rank RDIMM 6GB
(6x 1GB DIMMs)
12GB
(6x 2GB DIMMs)
Dual Rank RDIMMs 12GB
(6x 2GB DIMMs)
24GB
(6x 4GB DIMMs)
Quad Rank RDIMMs 16GB
(4x 4GB DIMMs)
32GB
(4x 8GB DIMMs)
Table 8. RDIMM Maximum configuration
Intel
®
Server Board S3420GP has the following limitations on RDIMM:
Note: Intel
®
Server Board S3420GPV has two DIMM slots per channel on board and totally four
DIMM slots which support maximum RDIMM size to 16GB (4x 4GB DIMMs) because of thermal
limitation without BMC control.
 No support for LV DIMMs
 256Mb/512Mb technology, x4 and x16 DRAMs on RDIMM are NOT supported
 All channels in a system will run at the fastest common frequency
 No mixing of registered and unbuffered DIMMs
Note : 1066MHz or 1333MHz RDIMMs run at 800MHz.
3.3 Intel
®
3420 Chipset PCH
The Intel
®
3420 Chipset component is the Platform Controller Hub (PCH). The PCH is designed
for use with Intel
®
processor in a UP server platform. The role of the PCH in Intel
®
Server Board
S3420GP is to manage the flow of information between its eleven interfaces:
 DMI interface to Processor
